inspirational|FOCUS BE01.jpg|Manual wheelchair Invacare Rea Focus
Discontinued product Discontinued product



cover|FOCUS CV01.jpg|Manual wheelchair Rea Focus
cover|FOCUS CV05.jpg|Manual wheelchair Rea Focus
cover|FOCUS MP03.jpg|Manual wheelchair Rea Focus
cover|FOCUS OF08.jpg|Manual wheelchair Rea Focus
cover|FOCUS OF29.jpg|Manual wheelchair Rea Focus
cover|FOCUS CV01.jpg|Manual wheelchair Rea Focus
cover|FOCUS CV05.jpg|Manual wheelchair Rea Focus
cover|FOCUS MP03.jpg|Manual wheelchair Rea Focus
cover|FOCUS OF08.jpg|Manual wheelchair Rea Focus
cover|FOCUS OF29.jpg|Manual wheelchair Rea Focus
cover|FOCUS CV01.jpg|Manual wheelchair Rea Focus
cover|FOCUS CV05.jpg|Manual wheelchair Rea Focus
cover|FOCUS MP03.jpg|Manual wheelchair Rea Focus
cover|FOCUS OF08.jpg|Manual wheelchair Rea Focus
cover|FOCUS OF29.jpg|Manual wheelchair Rea Focus
Folding brace chassis construction
Folding brace chassis construction
Ensures negligible wheel resistance.
Optimal use
Optimal use
Push the vertical frame bar into position for optimal body balance. To adjust the rear seat height, push the rear wheel attachment either up or down.
Adjustable seat depth
Adjustable seat depth
Enables rear and front end customisation. Up to 75 mm seat depth extension is possible.
Bi angular backrest
Bi angular backrest
Afford adjustability to an infinite range of body positions. The upholstery is also tension adjustable, and the whole backrest is depth adjustable.
Anti-tipper
Anti-tipper
Easy to use height-adjustable, anti-tipper. For adjustment, just press the small green plate. Tube end serves as tipping aid.
Adjustable seat width
Adjustable seat width
Accommodates a wide range of body sizes and types. The armrest attachment is easily adjusted for wider seat width.
Wind and rain cover
myBlanket

Stay warm and dry with this weather resistant blanket. Packs to a small compact size when not in use. An ideal option for wheelchairs and mobility scooters. Discover more here

By submitting my information, I acknowledge that I have read and understand Invacare's privacy notice.
Specifications & Downloads
Technical data
Technical data
Seat width

Seat width

380 / 405 / 430 / 455 / 480 / 505 mm

Seat depth

Seat depth

Low version: 375 - 450 mm High version: 425 - 500 mm

Seat angle

Seat angle

0° / 3° / 6°

Seat height

Seat height

Low version: 365 - 490 mm / High version: 415 - 540 mm

Backrest angle

Backrest angle

Angle adjustable: -6 - +13° / Reclining: 0 - 30° / Biangular: -6 - +13° / ±25°

Backrest height

Backrest height

Angle adjustable: 380 - 460 mm / Reclining: 500 mm / Biangular: 410 - 500 mm

Front frame angle

Front frame angle

80° / 90° / 0° - 80°

Length of footrests

Length of footrests

330 - 530 mm

Armrest height

Armrest height

190 - 290 mm

Driving unit width

Driving unit width

Seat width + 220 mm

Total width folded

Total width folded

320 mm

Total length

Total length

900 - 1195 mm

Total height

Total height

745 - 1320 mm

Max. safe slope

Max. safe slope

Max. User weight

Max. User weight

135 / 150 kg

Total weight

Total weight

16.2 kg

The heaviest part

The heaviest part

10 kg

Crash tested

Crash tested

Frame colour

Frame colour

Shining blue, Pearl Grey, Slate Grey

Colour (other)

Colour (other)

Black Dartex, Black Jemima, Black plush
