Invacare Platinum Mobile Portable oxygen contentrator

The Invacare Platinum Mobile oxygen concentrator

Platinum Mobile is  the latest innovative portable oxygen concentrator from the world-leading manufacturer of oxygen therapy – Invacare. With over 30 years in the oxygen therapy industry, Invacare boasts of producing exceptional oxygen concentrators with enhanced functions that meet users' needs adequately. The Platinum Mobile concentrator includes the latest in pulsed flow technology to cover clinical patient needs with five individual pulse setting positions. Platinum Mobile also comes with a stylish design and features an intuitive interface, thus bringing simplicity and innovation together in a compact, lightweight, quiet, and robust package.

The Invacare Platinum Mobile Concentrator, simple intuitive
The Invacare Platinum Mobile Concentrator in context
The Invacare Platinum Mobile Concentrator, battery design
The Invacare Platinum Mobile Concentrator, weather resistant
The Invacare Platinum Mobile Concentrator in context
The Invacare Platinum Mobile Concentrator
The Invacare Platinum Mobile Concentrator
The Invacare Platinum Mobile Concentrator
The Invacare Platinum Mobile Concentrator
The Invacare Platinum Mobile Concentrator, simple intuitive
The Invacare Platinum Mobile Concentrator in context
The Invacare Platinum Mobile Concentrator, battery design
The Invacare Platinum Mobile Concentrator, weather resistant
The Invacare Platinum Mobile Concentrator in context
The Invacare Platinum Mobile Concentrator
The Invacare Platinum Mobile Concentrator
The Invacare Platinum Mobile Concentrator
The Invacare Platinum Mobile Concentrator
The Invacare Platinum Mobile Concentrator, simple intuitive
The Invacare Platinum Mobile Concentrator in context
The Invacare Platinum Mobile Concentrator, battery design
The Invacare Platinum Mobile Concentrator, weather resistant
The Invacare Platinum Mobile Concentrator in context
The Invacare Platinum Mobile Concentrator
The Invacare Platinum Mobile Concentrator
The Invacare Platinum Mobile Concentrator
The Invacare Platinum Mobile Concentrator

The Invacare Platinum Mobile is built to meet users' needs at every stage. The Platinum Mobile concentrator is practically the best oxygen partner for more active chronic respiratory insufficiency patients. It also helps to minimise the risk factors associated with interstitial lung diseases. Platinum Mobile is user-friendly and simple. Below are some key features of this excellent oxygen concentrator:

  • Clinical efficiency: It features the advanced Sensi-Pulse technology – designed to mimic the volume delivered by continuous flow delivering only clinically beneficial oxygen at the beginning of inspiration, in turn allowing the maximum opportunity for gas exchange.

  • Impact protected: It is designed to withstand a shock to the unit through design features such as foam encapsulated compressor, reinforced bumpers, and latch free doors for shock dissipation.

  • Serviceability: The design allows easy access for maintenance teams, saving on both scheduled costs and time.

  • Unique battery design: It has a top-load battery for easy access, two battery compartments, hot-swap capability for continuous use, and an integrated battery indicator.

  • Lightweight: At only 2.22 kg*, the Platinum Mobile is compact and lightweight, promoting ambulation. *: with one battery and without carry bag

  • Sound level: It has a sound level of <40dBA that gives patients confidence to go to even the quietest of places such as the cinema or library.

Smart interface
Smart interface

Large, clear icons. Sealed, easy press buttons. Backlit LCD screen to show clear messages.

Unique battery design
Unique battery design

Top load battery foreasy access. 2 battery compartments Hot swap capability for continuous use. Integrated battery indicator.

3 in 1 carry bag
3 in 1 carry bag

Convertible to handbag, messenger bag or backpack style. Rubber bumper and retainer ring. Clearly printed visual aids. Air inlet channels.

Find Sales Offices

Find your dealer

Search for your nearest Invacare Retailer by completting the fields below.

Dealer map

Search for your nearest Invacare Retailer by completing the fields below.

Leave us a message

We will be happy to help you! If you wish to contact us feel free to fill in the below. We will reply very soon. Note that the personal data you will provide will not be used or stored unless you would like to stay connected. Feel free to read more about our Invacare Privacy Policy at the bottom of this page.

Specifications & Downloads

Technical data
Technical data
Height

Height

239 mm

Width

Width

188 mm

Total depth

Total depth

94 mm

Weight

Weight

2.22 kg concentrator 0.45 kg supplemental battery 0.34 kg carry bag

AC charger

AC charger

100-240 VAC 50-60 Hz

DC charger

DC charger

11-16 VDC

FAA

FAA

FAA compliant

Pulse dose delivery

Pulse dose delivery

Settings 1 - 5 Up to 1000 ml per minute

0² purity

0² purity

87 - 96%

Environmental tolerance

Environmental tolerance

Concentrator IP22 env.t° from 5°C to 40°C

Sound level

Sound level

40 db(A) at setting 2

Power consumption

Power consumption

24W at setting 2

Battery charging time

Battery charging time

2h20min with 1 battery 4h40min with 2 batteries

Trigger sensitivity

Trigger sensitivity

0.18 cm H2O average with ≤0,18 cm H2O at Setting 2 at 20 bpm

Nasal cannula length

Nasal cannula length

From 1200 mm to 2100 mm for best efficiency
